| 产品 系列 | 功率 (W) |
输出电流 (mA) |
输入电压 (VDC) |
输出电压 (VDC) |
输出路数 (NO.) |
隔离电压 (VDC) |
封装形式 | 下载 |
|---|---|---|---|---|---|---|---|---|
| HNM30W-48S15 | 30 | 2000 | 18-75 | 15 | 1 | 1500 | 50.8X25.4X10.2(mm³) |
|
| HNM30W-48S24 | 30 | 1250 | 18-75 | 24 | 1 | 1500 | 50.8X25.4X10.2(mm³) |
|
| HNM30W-48S28 | 30 | 1100 | 18-75 | 28 | 1 | 1500 | 50.8X25.4X10.2(mm³) |
|
| HNM30W-48S48 | 30 | 600 | 18-75 | 48 | 1 | 1500 | 50.8X25.4X10.2(mm³) |
|
| HNM30W-48D12 | 30 | 1250 | 18-75 | ±12 | 2 | 1500 | 50.8X25.4X10.2(mm³) |
|
| HNM30W-48D15 | 30 | 1000 | 18-75 | ±15 | 2 | 1500 | 50.8X25.4X10.2(mm³) |
|
| HNM30W-48D24 | 30 | 600 | 18-75 | ±24 | 2 | 1500 | 50.8X25.4X10.2(mm³) |
|
| HNM15W-24S33 | 13.2 | 4000 | 9-36 | 3.3 | 1 | 1500 | 25.4X25.4X10.2(mm³) |
|
| HNM15W-24S05 | 15 | 3000 | 9-36 | 5 | 1 | 1500 | 25.4X25.4X10.2(mm³) |
|
| HNM15W-24S12 | 15 | 1250 | 9-36 | 12 | 1 | 1500 | 25.4X25.4X10.2(mm³) |
|
| HNM15W-24S15 | 15 | 1000 | 9-36 | 15 | 1 | 1500 | 25.4X25.4X10.2(mm³) |
|
| HNM15W-24S24 | 15 | 630 | 9-36 | 24 | 1 | 1500 | 25.4X25.4X10.2(mm³) |
|
| HNM15W-24S28 | 15 | 540 | 9-36 | 28 | 1 | 1500 | 25.4X25.4X10.2(mm³) |
|
| HNM15W-24S48 | 15 | 320 | 9-36 | 48 | 1 | 1500 | 25.4X25.4X10.2(mm³) |
|
| HNM15W-24D05 | 15 | 150 | 9-36 | ±5 | 2 | 1500 | 25.4X25.4X10.2(mm³) |
|
| HNM15W-24D12 | 15 | 630 | 9-36 | ±12 | 2 | 1500 | 25.4X25.4X10.2(mm³) |
|
| HNM15W-24D15 | 15 | 500 | 9-36 | ±15 | 2 | 1500 | 25.4X25.4X10.2(mm³) |
|
| HNM15W-24D24 | 15 | 320 | 9-36 | ±24 | 2 | 1500 | 25.4X25.4X10.2(mm³) |
|
| HNM15W-48S33 | 13.2 | 4000 | 18-75 | 3.3 | 1 | 1500 | 25.4X25.4X10.2(mm³) |
|
| HNM15W-48S05 | 15 | 3000 | 18-75 | 5 | 1 | 1500 | 25.4X25.4X10.2(mm³) |
|
